Technical Data

∙ Stitch type 301 lock stitch
∙ Max. sewing speed 2,500 spm
∙ Max. stitch length 6.0 mm
∙ Max. top feed stroke 7.0 mm
∙ Max. fabric clearance 16 mm
∙ Needle system DP×17 / 135×17
∙ Needle size Nm 125–180
∙ Balance wheel 80 mm eff. Dia.
∙ Recommended motor power minimum 0.55 kW

Clearance under the arm
260×110 mm

Lubrication system

Carton dimensions and gross weights for sewing head
61,5×29,5×62 cm; 46 kg
