Technical Data

∙ Optimized thread guides for individual adjustment of each single needle
∙ Stitch type 605 (cover stitch)
∙ Max. sewing speed 6,000 spm. (GK335)
∙ Differential drop feed; Max. stitch length 4.5 mm
∙ Balance wheel 55 mm eff. Dia.

Clearance under the arm
215x113 mm

Fully automatic lubrication system

Carton dimensions and gross weights for sewing head
GK335:                                             58x45x63 cm, 48 kg
GK335/11 (motor included):                63x45x63 cm, 51 kg
