Technical Data

∙ Stitch type 301
∙ Max. sewing speed 2,700 spm.
∙ Max. stitch length 0.1-12.7 mm
∙ Direct-drive mini-motor on main shaft (220-230 V)
∙ X-Y-Movement controlled by stepping motors
∙ Memory capacity up to 2 MB (about 400,000 stitches)
∙ Vibrating presser foot niveau adjustable according to material thickness
∙ Sewing programs can be easily transfered by a SD Memory Card

Fully automatic oil pump lubrication system

Carton dimensions and gross weights
TC131-0705: 140×102×133 cm, 250 kg (packed in wooden crate)
