Technical Data

∙ Stitch type 301
∙ Vertical hook
∙ Max. sewing speed 2,500 spm. (GC20665)
∙ Max. stitch length 9 mm
∙ Max. fabric clearance 16 mm with knee lever
∙ Balance wheel 93 mm eff. Dia.

Clearance under the arm
∙ GC20665           260×110 mm
∙ GC20665-L25    660×110 mm

Automatic oil pump lubrication system

Carton dimensions and gross weights for sewing head
∙ GC20665                         74×34×70 cm, 50 kg
∙ GC20665 D2T3              74×34×70 cm, 50 kg
∙ GC20665 L25               115×34×70 cm, 63 kg
∙ GC20665 L25 D2T3     115×34×70 cm, 63 kg
