General Features
Workspace - 11.25" Long arm to the right on the needle
Lighting - Almost 11" of full - spectum lighting around the needle with five adjustable brightness settings
Needle threader - Easy to use, automatic needle threading system
Bobbin winder - Independent bobbin winder system with adjustable winding speed
Wireless - Wireless LAN capability for exchange of embroidery date with PE Design 11 and My Design Snap
Thread tension - Automatic thread tension
Thread cutter - Trims upper and lower threads automatically
Presser foot - Automatic presser foot lift and extra high lift
Thread sensors - Gives you a warning when your upper and lower threads are running low
Teaching movies - Up to 24 built in teaching videos and MP4 plaability
Environment - Save energy with the Eco and Deep sleep modes
My design centre - Create your own designs on screen
My desgin snap - Mobile app for perfect placement of embroidery designs
LCD display - Large and clear 10.1" (800 x 1280px) built in HD LCD display
Intuitive user interface - Easy to use screen layout and realistic preview of selected stitches and patterns
USB connectivity - Two high speed USB ports to upload designs easilly.
Multilingual - 12 built in languages
Safety features -Easily disengage needle to make changing presser feet and needles safer, and lock the screen to avoid any accidental stitch changes.
Embroidery features
Embroidery area - Large 9.5" x 14" 240mm x 360mm embroidery area
Embroidery Speed - Up to 1050 stitches per minute
Built in designs - Total of 727 embroidery patterns including 101 disney, monogram and buttonhole shapes
Built in fonts - Built in 24 embroidery fonts (22 alphabet & 2 cyrillic)
Text edit functions - Simplified user interface for text input and editing, with various editing capabilities such as curving, arraying and space adjustment
Font sizes - S/M/L size for font designs
Built in frame designs - 140 frame pattern combinations
Thread trimming - Jump stitch thread trimmign with thread wiper
Density - On screen auto density adjustment (stitch to block) available for embroidery and letters
LED pointer - Laser pointer for precise pattern placement
Advanced editing functions - Design editing, flip designs horizontally, pattern rotating (0.1, 10 and 90 degrees) drag and drop operation, zoom up to 200%
Basting - embroidery basting
Colour shuffling - Colour shuffling function that can choose one thread brand with more colour variations, with pinning and favourite mark capability
Stippling - No fuss stippling in embroidery edit
Selecting designs - Advanced multiple design selection
Colour change - Direct touch button for changing colours of embroidery patterns
Resume function - Resume your embroidery at the exact spot where you stopped incase of a power failure or accidental interruption
Applique Creator - Built in applique creator , create multiple appliques in one hoop
Optimised Colour Sorting - Quickly sort colours in different designs for optimised sewing order and to minimise thread changes
Frame detection - Automatic embroidery frame size detection
Progress bar - View the progress of an embroidery pattern or individual colour, and use to move forwards / backwards through the design
Thread palettes - Select various thread bands for built in and external designs
Included frames - Two standard frames, compatible with My Design Snap , included 240mm x 360mm (9.5" x 14") and 130mm x 180mm (5" x 7")
Sewing Features
Built in sewing stitches - Total of 727 utility, decorative stitches and buttonholes
Lettering fonts - Four built in sewing lettering fonts (Three alphabet, 1 cyrillic)
Sewing speed - Sew up to 1050 stitches per minute
Combination stitches - Individual adjustment for combined stitches (depending on category)
My Custom stitch - Gives you the ability to combine and edit custom stitches. Includes 185 built in sample stitches
Laser guideline marker - Guideling marker with 19mm side shift capability
ICAPS fabric sensor system - Continuously adjusts presser foor presure
Lock stitch - Reinforcement stitch at start and end of sewing
Dual feed - Digital dual feed system for even and consisten sewing on all fabrics
Pivot and foot height - Lightning quick pivoting functionality with customisable foot height
SFDS - Square feeding system with powerful and long feed dogs
Needle plate detector - Needle plate detector for safe operation
Straight stitch - Straight stitch needle plate and straight stitch foot included
Ruler - Ruler design with zero mark at the needle
Free motion - Presser foot height adjusts according to the thickness of the fabric
Drop feed function - Convert to free motion mode easily with a touch of a button on screen
Automatic presser foot functions - Bring presser foot down automatically using the Start/Stop button, knee lift and foot pedal
